Camlock Coupling |
Type A |
Type B |
|
|
|
|
|
Type C |
Type D |
Type E |
|
|
|
|
|
Type F |
Type DC |
Type DP |
| AL | A | B | C | D | E | F | DC | DP |
| 1/2" | A50AL | B50AL | C50AL | D50AL | E50AL | F50AL | DC50AL | DP50AL |
| 3/4" | A75AL | B75AL | C75AL | D75AL | E75AL | F75AL | DC75AL | DP75AL |
| 1" | A100AL | B100AL | C100AL | D100AL | E100AL | F100AL | DC100AL | DP100AL |
| 11/4" | A125AL | B125AL | C125AL | D125AL | E125AL | F125AL | DC125AL | DP125AL |
| 11/2" | A150AL | B150AL | C150AL | D150AL | E150AL | F150AL | DC150AL | DP150AL |
| 2" | A200AL | B200AL | C200AL | D200AL | E200AL | F200AL | DC200AL | DP200AL |
| 21/2" | A250AL | B250AL | C250AL | D250AL | E250AL | F250AL | DC250AL | DP250AL |
| 3" | A300AL | B300AL | C300AL | D300AL | E300AL | F300AL | DC300AL | DP300AL |
| 4" | A400AL | B400AL | C400AL | D400AL | E400AL | F400AL | DC400AL | DP400AL |
| 5" | A500AL | B500AL | C500AL | D500AL | E500AL | F500AL | DC500AL | DP500AL |
| 6" | A600AL | B600AL | C600AL | D600AL | E600AL | F600AL | DC600AL | DP600AL |
| 8" | A800AL | B800AL | C800AL | D800AL | E800AL | F800AL | DC800AL | DP800AL |
| 10" | A1000AL | B1000AL | C1000AL | D1000AL | E1000AL | F1000AL | DC1000AL | DP1000AL |
| 12" | A1200AL | B1200AL | C1200AL | D1200AL | E1200AL | F1200AL | DC1200AL | DP1200AL |
| SS304 | A | B | C | D | E | F | DC | DP |
| 1/2" | A50S4 | B50S4 | C50S4 | D50S4 | E50S4 | F50S4 | DC50S4 | DP50S4 |
| 3/4" | A75S4 | B75S4 | C75S4 | D75S4 | E75S4 | F75S4 | DC75S4 | DP75S4 |
| 1" | A100S4 | B100S4 | C100S4 | D100S4 | E100S4 | F100S4 | DC100S4 | DP100S4 |
| 11/4" | A125S4 | B125S4 | C125S4 | D125S4 | E125S4 | F125S4 | DC125S4 | DP125S4 |
| 11/2" | A150S4 | B150S4 | C150S4 | D150S4 | E150S4 | F150S4 | DC150S4 | DP150S4 |
| 2" | A200S4 | B200S4 | C200S4 | D200S4 | E200S4 | F200S4 | DC200S4 | DP200S4 |
| 21/2" | A250S4 | B250S4 | C250S4 | D250S4 | E250S4 | F250S4 | DC250S4 | DP250S4 |
| 3" | A300S4 | B300S4 | C300S4 | D300S4 | E300S4 | F300S4 | DC300S4 | DP300S4 |
| 4" | A400S4 | B400S4 | C400S4 | D400S4 | E400S4 | F400S4 | DC400S4 | DP400S4 |
| 5" | A500S4 | B500S4 | C500S4 | D500S4 | E500S4 | F500S4 | DC500S4 | DP500S4 |
| 6" | A600S4 | B600S4 | C600S4 | D600S4 | E600S4 | F600S4 | DC600S4 | DP600S4 |
| 8" | A800S4 | B800S4 | C800S4 | D800S4 | E800S4 | F800S4 | DC800S4 | DP800S4 |
| 10" | A1000S4 | B1000S4 | C1000S4 | D1000S4 | E1000S4 | F1000S4 | DC1000S4 | DP1000S4 |
| 12" | A1200S4 | B1200S4 | C1200S4 | D1200S4 | E1200S4 | F1200S4 | DC1200S4 | DP1200S4 |
| SS316 | A | B | C | D | E | F | DC | DP |
| 1/2" | A50S6 | B50S6 | C50S6 | D50S6 | E50S6 | F50S6 | DC50S6 | DP50S6 |
| 3/4" | A75S6 | B75S6 | C75S6 | D75S6 | E75S6 | F75S6 | DC75S6 | DP75S6 |
| 1" | A100S6 | B100S6 | C100S6 | D100S6 | E100S6 | F100S6 | DC100S6 | DP100S6 |
| 11/4" | A125S6 | B125S6 | C125S6 | D125S6 | E125S6 | F125S6 | DC125S6 | DP125S6 |
| 11/2" | A150S6 | B150S6 | C150S6 | D150S6 | E150S6 | F150S6 | DC150S6 | DP150S6 |
| 2" | A200S6 | B200S6 | C200S6 | D200S6 | E200S6 | F200S6 | DC200S6 | DP200S6 |
| 21/2" | A250S6 | B250S6 | C250S6 | D250S6 | E250S6 | F250S6 | DC250S6 | DP250S6 |
| 3" | A300S6 | B300S6 | C300S6 | D300S6 | E300S6 | F300S6 | DC300S6 | DP300S6 |
| 4" | A400S6 | B400S6 | C400S6 | D400S6 | E400S6 | F400S6 | DC400S6 | DP400S6 |
| 5" | A500S6 | B500S6 | C500S6 | D500S6 | E500S6 | F500S6 | DC500S6 | DP500S6 |
| 6" | A600S6 | B600S6 | C600S6 | D600S6 | E600S6 | F600S6 | DC600S6 | DP600S6 |
| 8" | A800S6 | B800S6 | C800S6 | D800S6 | E800S6 | F800S6 | DC800S6 | DP800S6 |
| 10" | A1000S6 | B1000S6 | C1000S6 | D1000S6 | E1000S6 | F1000S6 | DC1000S6 | DP1000S6 |
| 12" | A1200S6 | B1200S6 | C1200S6 | D1200S6 | E1200S6 | F1200S6 | DC1200S6 | DP1200S6 |
Polypropylene (Fiber Reinforced) Camlock Coupling
| PP | A | B | C | D | E | F | DC | DP |
| 1/2" | A50PP | B50PP | C50PP | D50PP | E50PP | F50PP | same 3/4" | same 3/4" |
| 3/4" | A75PP | B75PP | C75PP | D75PP | E75PP | F75PP | DC75PP | DP75PP |
| 1" | A100PP | B100PP | C100PP | D100PP | E100PP | F100PP | DC100PP | DP100PP |
| 11/4" | A125PP | B125PP | C125PP | D125PP | E125PP | F125PP | same1.5" | same1.5" |
| 11/3" | A130PP | B130PP | C130PP | D130PP | E130PP | F130PP | same1.5" | same1.5" |
| 11/2" | A150PP | B150PP | C150PP | D150PP | E150PP | F150PP | DC150PP | DP150PP |
| 2" | A200PP | B200PP | C200PP | D200PP | E200PP | F200PP | DC200PP | DP200PP |
| 3" | A300PP | B300PP | C300PP | D300PP | E300PP | F300PP | DC300PP | DP300PP |
| 4" | A400PP | B400PP | C400PP | D400PP | E400PP | F400PP | DC400PP | DP400PP |
11/3": 11/2" coupler / adapter *11/4" thread / shank
Polypropylene (Fiber Reinforced) 90 degree Elbow Camlock Coupling
| PP | A | B | C | D | E | F |
| 1.5" | A150-90PP | B150-90PP | C150-90PP | D150-90PP | E150-90PP | F150-90PP |
| 2" | A200-90PP | B200-90PP | C200-90PP | D200-90PP | E200-90PP | F200-90PP |
